Fiche Technique

Spécifications

* Zoom: F=3.2- 86.4mm, 27X Optical Zoom

* Pan:355°,Tilt:100°

* 1/4" SONY CCD 420TVL H.264 compression

* DI:720x576 half-D1(576*354) CIF:352x288 QCIF:176x144 * Built-in POE function(Power Over Ethernet)

* Two channel audio: Built-in microphone and you can also connect to pickup

* 1ch alarm input, 1ch output Alarm

* 10/100M bps high-speed Ethernet automatic detection

* Motion detection, can be set to the e-mail notify or transmit images to FTP

* High safe, set up multiple user accounts and passwords

* Multi-level access: administrator / authorized user / anonymous login.

* Support up to 20 remote viewers at the same time

* Video file formats: AV or AVI for optional

* To provide a multi-screen Windows software (1/4/6/8/9/12/16/20/25/30ch optional)

* 32-bit ARM9 RISC CPU, 2MB flash memory, 8 MB SDRAM, 32MB DDRAM

* High-quality audio decode: G.726ADPCM 16-40kbps

* Relative humidity: 20%~80%RHG

* Work temperature: -10℃~55℃

* Protocol: TCP/IP, PING, HTTP, UDP

* Power supply: DC 12V

* Accessories: one power, one disk, the disk includes software and manual
